'mode tcp' performace degradation with two different backends

[doka.ua]

I’m trying to test new connections rate in ‘mode tcp’ with the following config

frontend default_fe
  mode tcp
  bind *:443
  default_backend default_be

backend default_be
  mode tcp
  balance roundrobin
  # three autonomous apache servers
  server s3_v4   127.0.0.1:8443
  server s1_v4   172.16.37.1:8443
  server s2_v4   172.16.37.2:8443

using and command:

wrk -t12 -c2500 -d10s -H “Connection: close” https://my_site:443/

and the problem is:

• when I’m using the single backend (either local or remote), RPS is about 10-11k
• when I’m using two or more different backend (in any combination) the performance degrades to 2-3k RPS

Backends performance is ok - when I’m running three simultaneous wrk to all three backends, every of them gives ~10-11k RPS

The problem appears with either leastconn or roundrobin or even random algo and not present with source or first - so as soon as haproxy needs to consider destinations in balance algo, it degrades.

Will appreciate if anyone can point me on something I’m doing or thinking wrong Thank you

Examples

Single backend:

root@px:~# wrk -t12 -c2500 -d10s -H "Connection: close" https://xxxxxxxxxxx.com:443/
Running 10s test @ https://xxxxxxxxxxx.com:443/
  12 threads and 2500 connections
  Thread Stats   Avg      Stdev     Max   +/- Stdev
    Latency    24.96ms   36.87ms   1.91s    95.62%
    Req/Sec     0.90k   293.26     1.58k    73.94%
  100147 requests in 10.09s, 42.98MB read
Requests/sec:   9926.99
Transfer/sec:      4.26MB

Two backends:

root@px:~# wrk -t12 -c2500 -d10s -H "Connection: close" https://xxxxxxxxxxx.com:443/
Running 10s test @ https://xxxxxxxxxxx.com:443/
  12 threads and 2500 connections
  Thread Stats   Avg      Stdev     Max   +/- Stdev
    Latency    93.16ms  122.31ms   1.09s    87.70%
    Req/Sec   353.96    548.95     2.07k    84.66%
  24908 requests in 10.17s, 10.69MB read
  Socket errors: connect 0, read 0, write 0, timeout 1
Requests/sec:   2449.70
Transfer/sec:      1.05MB

Haproxy configuration (skipping general) is

looks nothing special -

global
    hard-stop-after 1m
    daemon
    # see also `systemctl edit haproxy`
    maxconn 256000
    cpu-policy performance
    # update shards below in listener to == nbthread
    nbthread 16
    cpu-map 1/1  4
    cpu-map 1/2  32
    ...

defaults
    option  dontlognull
    mode    http
    http-reuse always
    backlog 65536
    retries 3
    option  redispatch

    option  nolinger
    timeout connect     5s
    timeout client      35s
    timeout client-fin  40s
    timeout server      35s
    timeout server-fin  40s

    timeout http-request 5s
    timeout http-keep-alive 15s

frontend ident_fe
    mode tcp
    bind *:443 shards 16
    default_backend default_ident_be

backend default_ident_be
    mode tcp
    fullconn 120000
    option tcp-check
    default-server check inter 3s rise 2 fall 2
    balance roundrobin
    server ident3_v4   127.0.0.1:13443
    server ident1_v4   172.16.37.1:13443
    server ident2_v4   172.16.37.2:13443

[lukastribus]

You have already filed a bug on Github about this:

'mode tcp' performace degradation with two different backends

Let’s use a single support channel, not multiple. Thank you.
